VSC II LED Luminaire
VSC-II – part of our V-Collection is a high performance architectural LED luminaire to be used in outdoor lighting applications. Sleek design takes advantage of the low profile LED lamp technology. Superior thermal management allows for maximum LPW output.
Resources
Key Features
- Precision-Engineered Construction
- Robust cast-aluminum housing for long-term durability in demanding environments
- Separate, sealed driver compartment enhances thermal management and extends component life
- Robust cast-aluminum housing for long-term durability in demanding environments
- Optical Performance
- Seventeen precision-engineered optical distributions
- Optimized to deliver uniform illumination while minimizing glare and off-site spill
- Seventeen precision-engineered optical distributions
- Light Quality
- Correlated Color Temperatures (CCT): 2700K, 3000K, 3500K, 4000K, and 5000K
- Engineered for visual comfort, clarity, and application flexibility
- Correlated Color Temperatures (CCT): 2700K, 3000K, 3500K, 4000K, and 5000K
- Output & Electrical
- Lumen packages from 2,300 to 23,000+ lumens
- Wattage range: 16–181 watts
- Driver options:
- 120–277V universal voltage
- 347V and 480V configurations available
- 120–277V universal voltage
- Lumen packages from 2,300 to 23,000+ lumens
- Controls & Compliance
- Button-type photocell
- Title 24–compliant motion sensor
- 0–10V dimming
- Emergency battery pack option for life-safety applications
- Button-type photocell
- Installation & Mounting
- Integrated conduit box with (2) ½″ threaded conduit entries for simplified wiring
- Back plate option for retrofit and replacement installations
- Up-light configuration available for architectural and accent applications
- Integrated conduit box with (2) ½″ threaded conduit entries for simplified wiring
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
CRI
- 70 CRI
- 80 CRI
- 90 CRI
Color / Finish
- Black
- Bronze
- Custom
- Graphite
- Grey
- Silver Metallic
- Smooth Black
- Smooth White
- White
Controls Options
- Motion Sensor
- Photocell
Dimming Protocol
- 0-10 V
- ELV (Trailing Edge)
Lamp Life
- 100000 hrs
Lamp Source
- LED
Materials
- Aluminum
Ratings & Compliance
- DLC
- IP65
Voltage
- 120-277 V
- 347 V
- 480 V
- UNV
Warranty
- 5 yr
Watts
- 18 w
- 26 w
- 37 w
- 52 w
- 55 w
- 56 w
- 74 w
- 78 w
- 105 w
- 112 w
